MOTOR “UM” SERIES:FEATURES

  • Various Heads are interchangeable with Motor “UM” series for wider applications.
  • Stable rotation from low to high speed enables to apply to all sorts of working.
  • You are not tired with working because noise and vibration are controlled as low as possible.
  • 3 typical models are provided for your choice according to speed and torque.

.

UM20 High Torque Type

  • The most suitable for polishing required for low rotation speed but high torque.
  • Interchangeable heads
    [UT01] [UT02] [UT03] [UT05] [UT06] [UT07 ][UT08] [UT11] [UT12] [UT15]
Specifications Rotation speed : 800 – 8,000rpm
Max. torque : 900 g.cm (used with controller UC500C)
Weight : 175g (Curl cord is not included)
Size : diameter 31.6 x L98.3 mm
Accessories Handpiece rest stand (KP90-101)
Carbon brush 2 pcs (PKE60-103)

.

UM23 Speed Type

  • The most suitable for grinding because of speed type motor.
  • Interchangeable heads
    [UT01] [UT02] [UT03] [UT11] [UT12] [UT15]
Specifications Rotation speed : 3,000 -30,000rpm
Max. torque : 650 g.cm (used with controller UC500C)
Weight : 175g (Curl cord is not included)
Size : diameter 31.6 x L98.3 mm
Accessories Handpiece rest stand (KP90-101)
Carbon brush 2 pcs (PKE60-103)
